Elevated Flame – Mod. EL

The flare consists of a burner installed at elevated position, equipped with a high-energy ignition Pilot and a flame detection system via Thermocouple.
The combustion air is natural conveyed from the bottom part of flame shield and the combustion temperature will be max. 800 °C.
The height of this flare is calculated according to the heat radiation released from burning to the ground and that will ensure an adequate level of protection to people and equipment that are within range of the flare.
This type of Flare develops a luminous flame which extends beyond the top part, so the combustion temperature and emissions monitoring are difficult to control.
The ignition system is automatic type, operated by the electrical panel installed of the flare’s bottom side and initially involves the pilot’s ignition and subsequently the opening of the main Biogas valve.
The gas train and all accessories such as valves, flame arrestor, pressure gauge and other, are installed at ground level.
