Jib Crane

This equipment allows the removal and laying of the Pig from the inside of the retractable cradle of the Handling System of the launching traps, using a crane equipped flag with a manual winch for vertical lifting fixed to a sliding cart on wheels which allows the horizontal translation within the beam.

The beam will be equipped with the column, with the pivot pin on bushings that allow the complete rotation to 360 ° during the loading and unloading operations of the Pig.

The base of the column is equipped with anchoring to the floor box, which allows attachment using bolts; this is positioned close to the Handling system, with a minimum distance which allows the removal of the pig.

Version with electric lifting winch is available on request.
